Getting started with TSP

Michael Hahsler and Kurt Hornik

Source: vignettes/TSP.Rmd
TSP.Rmd

The traveling salesperson problem asks for the shortest round trip that visits each city exactly once. The TSP package provides classes for representing traveling salesperson problems, several construction and improvement heuristics, and interfaces to the external Concorde solver.

This vignette covers the typical workflow:

  1. Create a problem from coordinates or a distance matrix.
  2. Find a tour with solve_TSP().
  3. Inspect, compare, and visualize solutions.

Installation

Install the released version from CRAN:

Then load the package:

Create a problem from coordinates

For locations described by coordinates, create a Euclidean traveling salesperson problem with ETSP(). Row names are used as city labels.

cities <- data.frame(
  x = c(0.15, 0.38, 0.62, 0.82, 0.78, 0.55, 0.28, 0.08),
  y = c(0.20, 0.08, 0.18, 0.42, 0.78, 0.92, 0.80, 0.52),
  row.names = LETTERS[1:8]
)

problem <- ETSP(cities)
problem
#> object of class 'ETSP'
#> 8 cities (Euclidean TSP)
n_of_cities(problem)
#> [1] 8
labels(problem)
#> [1] "A" "B" "C" "D" "E" "F" "G" "H"

An ETSP stores the coordinates directly. Most built-in heuristics convert it to a distance-based TSP internally. For very large coordinate sets this distance matrix can require substantial memory.

Solve the problem

solve_TSP() returns a TOUR, an integer permutation giving the order in which the cities are visited. The default combines arbitrary insertion with 2-opt improvement.

tour <- solve_TSP(problem, seed = 123)
tour
#> object of class 'TOUR'
#> result of method 'arbitrary_insertion+two_opt' for 8 cities
#> tour length: 2.430432
as.integer(tour)
#> [1] 7 6 5 4 3 2 1 8
labels(tour)
#> [1] "G" "F" "E" "D" "C" "B" "A" "H"
tour_length(tour)
#> [1] 2.430432

The stored tour length includes the final edge from the last city back to the first. A TSP solution is therefore a cycle, not an open path.

Plot the coordinates and the resulting tour with plot():

plot(problem, tour, main = "A tour through eight cities", tour_col = "steelblue")

Create a problem from distances

If pairwise distances or costs are already available, pass a dist object or a symmetric matrix to TSP().

distance_problem <- TSP(dist(cities))
distance_problem
#> object of class 'TSP'
#> 8 cities (distance 'euclidean')

distance_tour <- solve_TSP(distance_problem, method = "nn", start = 1)
distance_tour
#> object of class 'TOUR'
#> result of method 'nn' for 8 cities
#> tour length: 2.430432
tour_length(distance_tour)
#> [1] 2.430432

TSP() does not require distances to be Euclidean; they can represent any symmetric dissimilarity or cost. Missing connections can be represented by Inf, while NA values are not allowed.

Choose and compare heuristics

Construction heuristics build a tour from scratch. Common choices include nearest neighbor ("nn") and nearest, cheapest, farthest, or arbitrary insertion. Improvement heuristics such as "two_opt" start from an existing tour and try to shorten it.

methods <- c(
  "nearest neighbor" = "nn",
  "nearest insertion" = "nearest_insertion",
  "cheapest insertion" = "cheapest_insertion",
  "repetitive nearest neighbor" = "repetitive_nn"
)

tours <- lapply(methods, function(method) {
  solve_TSP(problem, method = method, seed = 123)
})

sort(vapply(tours, tour_length, numeric(1)))
#> repetitive nearest neighbor            nearest neighbor
#>                    2.430432                    2.430432
#>           nearest insertion          cheapest insertion
#>                    2.430432                    2.430432

Add two_opt = TRUE to refine a constructed tour, or explicitly improve an existing tour:

initial_tour <- solve_TSP(problem, method = "nn", start = 1)
improved_tour <- solve_TSP(
  problem,
  method = "two_opt",
  tour = initial_tour
)

c(
  initial = tour_length(initial_tour),
  improved = tour_length(improved_tour)
)
#>  initial improved
#> 2.430432 2.430432

Randomized methods support seed for reproducibility and rep for repeated starts. For example, the following returns the shortest of 20 random tours, each followed by 2-opt improvement:

repeated_tour <- solve_TSP(
  problem,
  method = "random",
  rep = 20,
  two_opt = TRUE,
  seed = 123
)
tour_length(repeated_tour)
#> [1] 2.430432

These methods are heuristics: a short tour is not necessarily an optimal tour. The "concorde" method can find an exact solution, and "linkern" provides the Chained Lin-Kernighan heuristic, but both require a separately installed Concorde executable. See ?Concorde for setup instructions.

Asymmetric problems

When the cost from city i to city j differs from the reverse direction, create an asymmetric problem with ATSP() from a square cost matrix.

cost <- matrix(
  c(
    0, 4, 1, 3,
    2, 0, 5, 1,
    3, 2, 0, 4,
    6, 3, 2, 0
  ),
  nrow = 4,
  byrow = TRUE,
  dimnames = list(LETTERS[1:4], LETTERS[1:4])
)

asymmetric_problem <- ATSP(cost)
asymmetric_tour <- solve_TSP(asymmetric_problem, method = "nn", start = 1)
asymmetric_tour
#> object of class 'TOUR'
#> result of method 'nn' for 4 cities
#> tour length: 10
tour_length(asymmetric_tour)
#> [1] 10

Most built-in heuristics work directly with both TSP and ATSP objects. Solvers that only accept symmetric problems can use the package’s automatic ATSP-to-TSP reformulation; see ?reformulate_ATSP_as_TSP.

Where to go next

The most useful help pages are:
